DESCRIPTION：
|
Size |
d |
d 1 |
d 2 |
D
|
|
|
|
W |
H1 |
|
|
|
|
Operating torque (N∙M) |
||||||
|
ANSI |
DIN |
JIS |
CNS |
ANSI |
DIN |
JIS |
CNS |
H |
L |
L1 |
H2 |
F |
M |
I |
||||||
|
1/2”(15) |
15 |
21.54 |
20.30 |
22.40 |
22.40 |
21.23 |
20.10 |
21.73 |
21.90 |
54.00 |
8.70 |
107.00 |
22.30 |
84.00 |
52.50 |
27.50 |
31.00 |
-- |
M6 |
2.00 |
|
3/4”(20) |
20 |
26.87 |
25.30 |
26.40 |
26.40 |
26.57 |
25.10 |
25.69 |
25.90 |
63.00 |
8.20 |
115.00 |
25.50 |
90.00 |
59.00 |
32.00 |
33.00 |
-- |
M6 |
2.50 |
|
1”（250 |
25 |
33.65 |
32.30 |
32.55 |
34.50 |
33.27 |
32.10 |
31.70 |
33.90 |
73.50 |
8.20 |
129.00 |
28.60 |
106.00 |
67.50 |
37.25 |
40.00 |
-- |
M6 |
4.00 |
|
1-1/4”(32) |
32 |
42.42 |
40.30 |
38.60 |
42.50 |
42.04 |
40.10 |
37.65 |
41.90 |
84.50 |
7.70 |
144.00 |
32.00 |
116.00 |
77.50 |
42.75 |
52.00 |
-- |
M8 |
5.00 |
|
1-1/2”(40) |
40 |
48.56 |
50.30 |
48.70 |
48.60 |
48.11 |
50.10 |
47.74 |
47.90 |
98.00 |
8.50 |
161.00 |
35.00 |
128.00 |
90.00 |
50.00 |
52.00 |
-- |
M8 |
7.5 |
|
2”(50) |
50 |
60.63 |
63.30 |
60.80 |
60.60 |
60.17 |
63.10 |
59.78 |
59.90 |
118.00 |
8.00 |
173.00 |
38.00 |
140.00 |
106.00 |
60.00 |
70.00 |
-- |
M8 |
10 |
